Capacity: | 50L, 100L, 168L, ... ,1000L | Sterilization Time: | 3H-99H |
---|---|---|---|
Working Temperature: | 40℃-65℃ | Door Opening Mode: | Handle |
Display: | LCD Touch Screen | Data Recording: | Printer Equipped |
Chamber Material: | 304 Stainless Steel | Thickness Of SUS: | ≥3mm |
Selection Of Sterilizers: | EO Gas | Voltage: | 220V 50/60hz |
Highlight: | 1000l Ethylene Oxide Sterilizer,Digital Display Ethylene Oxide Medical Sterilization,Digital Display Ethylene Oxide Sterilization Equipment |
The STE-GM series ethylene oxide sterilizer is a special sterilization equipment that uses pure ethylene oxide and ethylene oxide mixed gas to carry out low - temperature fumigation sterilization on items sealed in the sterilization chamber under certain temperature, pressure, humidity and a certain action time. Ethylene oxide gas is a very active chemical disinfectant. It not only achieves broad - spectrum sterilization, but also can achieve reliable sterilization.
Product Model | Power Supply | Inner Tank Capacity | Inner Tank Dimensions (Length×Width×Height, cm) | Outer Case Dimensions (Length×Width×Height, cm) |
STE-GM50 | AC220V 50Hz | 70L | 60*30*40 | 77*49*107 |
STE-GM100 | AC220V 50Hz | 120L | 60*40*50 | 77*60*115 |
STE-GM168 | AC220V 50Hz | 168L | 67*43*59 | 83*64*123 |
STE-GM200 | AC220V 50Hz | 200L | 70*47*62 | 86*65*126 |
STE-GM268 | AC220V 50Hz | 268L | 75*54*67 | 92*75*131 |
STE-GM300 | AC220V 50Hz | 300L | 80*54*69 | 99*77*133 |
STE-GM500 | AC220V 50Hz | 500L | 96*67*79 | 112*88*149 |
STE-GM800 | AC220V 50Hz | 800L | 103*87*90 | 121*108*161 |
STE-GM1000 | AC220V 50Hz | 1000L | 120*87*98 | 138*108*168 |
The ethylene oxide sterilizer produces a very specific alkylation effect through the contact of ethylene oxide with microorganisms, thus inhibiting the normal operation of the reaction groups of microorganisms and causing their metabolism to be disrupted and die.
①Simple Operation
One - key operation, microcomputer control, simple and convenient, with digital display of the sterilization process.
②Print Record
Record and print sterilization information during the sterilization process, facilitating inspection and filing.
③Filtration System
An inlet filtration system is installed, which can effectively filter out pathogens and microorganisms, avoiding secondary pollution of residual exhaust air intake.
Consumables for Ethylene Oxide Sterilizer:
Ethylene oxide gas, ethylene oxide biological indicator, ethylene oxide indicator tape, ethylene oxide indicator inner card, ethylene oxide indicator outer card, ethylene oxide packaging bag.
Direct Manufacturer Pricing: As the source factory, we eliminate middleman costs, providing global clients cost-effective sterilization solutions directly.
Efficient Direct Support: Our service team ensures rapid and efficient communication and support, handled entirely in-house from production to after-sales.
Flexible Custom Solutions: Leveraging strong technical expertise, we offer both standard models and fully customized equipment tailored to specific structural, functional, or control requirements.
Certified Quality & Safety: Every device undergoes strict quality control and holds international certifications (including CE, ISO 13485, ISO 9001), guaranteeing safety, stability, and long-term reliability.
