Capacity: | 100L, 130L, 190L | Door Structure: | Automatic Lifting Door |
---|---|---|---|
Number Of Plates: | 2 Layers Sterilizing Plates | Display: | LCD Touch Screen |
Material: | 304 Anti-corrosion Type Stainless Steel Or Aluminum 5052 | Data Recording: | Printer Equipped |
Control System: | Use Imported Siemens Smart Series PLC Control System | Dosing Type: | Cassette 12capsules/set |
Power: | 3.5kw | Sterilizing Temperature: | 50℃±5℃ |
Highlight: | 100L Hydrogen Peroxide Plasma Sterilizer,Cassette Dosing Hydrogen Peroxide Plasma Sterilizer,Cassette Dosing Low Temp Plasma Sterilizer |
Ideal for sterilizing heat-sensitive surgical instruments and endoscopes in hospitals, this low-temperature plasma system (50°C) completes validated cycles in 30 minutes. Ensure compliance and instrument longevity in medical/dental facilities with fully automated H₂O₂ plasma sterilization, featuring traceable data logging for audit-ready safety protocols.
No. |
Model |
Volume |
Chamber size(L*W*H) |
Dimension |
Power |
G.W(kg) |
Power supply |
1 |
STL-PC100 |
100L |
700 x 430 x 360mm |
1105×790×1765mm |
3.95 |
340 |
AC220V/50HZ |
2 |
STL-PC130 |
130L |
750 x 450 x 400mm |
1105×790×1765mm |
4.35 |
360 |
AC220V/50HZ |
3 |
STL-PC220 |
190L |
820 x 510 x 460mm |
1105×790×1765mm |
5.15 |
450 |
AC220V/50HZ |
Type |
Cassette H2O2 plasma sterilizer |
Heating method |
Electric |
Install environment |
5-45℃ |
Sterilizing temperature |
50℃ |
Working pressure |
50pa |
Sterilize agent |
Hydrogen peroxide solution(60%H202) |
Sterilizing time |
45-50min |
Parameter display |
LCD touch screen |
Door opening method |
Automatic |
Cassette |
12pcs/set support 6 sterilization cycles |
Efficient Sterilization: Utilizes vaporized hydrogen peroxide (H₂O₂) combined with plasma technology, achieving thorough sterilization even for cavity instruments up to 4 meters in length.
Low Temperature Operation: Maintains sterilization temperatures between 45°C and 55°C, making it ideal for heat- and moisture-sensitive instruments like endoscopes and plastic lumens.
Cassette-Type H₂O₂ Injection: The sterilant is filled via a sealed cassette system, automatically controlled by Siemens PLC for safe and precise delivery.
Advanced Touch Control: Equipped with a 7-inch LCD color touchscreen interface and Siemens smart PLC system, allowing one-button operation and real-time monitoring.
Data Traceability: Built-in thermal printer and USB interface ensure permanent recording and export of sterilization cycle data.
Smart Safety Features: Includes door interlock, barrier switch, vacuum phase protection, and fault diagnostics with on-screen alerts.
Durable and Hygienic Build: The chamber and door are made from corrosion-resistant 5052 aluminum alloy. The outer shell uses high-strength ABS material.
Compact and Easy Installation: No need for drainage, ventilation piping, or civil work. Built-in casters make it easy to move and install.
Reliable Components: Includes imported sensors (Japan), branded vacuum pump, transistor plasma power supply, and high-efficiency air and oil mist filtration.
Validated Performance: EMC and sterilization effectiveness tested and certified by provincial authorities.
Direct Manufacturer Pricing: As the source factory, we eliminate middleman costs, providing global clients cost-effective sterilization solutions directly.
Efficient Direct Support: Our service team ensures rapid and efficient communication and support, handled entirely in-house from production to after-sales.
Flexible Custom Solutions: Leveraging strong technical expertise, we offer both standard models and fully customized equipment tailored to specific structural, functional, or control requirements.
Certified Quality & Safety: Every device undergoes strict quality control and holds international certifications (including CE, ISO 13485, ISO 9001), guaranteeing safety, stability, and long-term reliability.
