Volume: | 200L | Door Structure: | Hand Wheel |
---|---|---|---|
Display: | Knob Control | Power: | 9kw |
Chamber Material: | Stainless Steel 304 | Chamber Size: | ø515*1000mm |
Net Weight: | 318kg | Working Temp.: | 138℃ |
Working Press.: | 0.25Mpa | Voltage: | 380v, 50hz, Three Phase |
Highlight: | CE Certified Horizontal Steam Sterilizer,Knob Control Display Horizontal Steam Sterilizer,Medical Equipment Sterilizer |
The microprocessor controlled automatic autoclave has a capacity of 200 L and a maximum working temperature of 134℃. Equipped with safety features like automatic shutofpreventing overload of current, auto protection aacinst raised temperature and pressure making a reliable anouser friendly device.
Model | STH-HK200 |
Volume | 200 Liters |
Sterilizing Chamber Volume | Ø515*1000mm |
Design pressure | 0.3Mpa |
Design temperature | 150℃ |
Max. Working pressure | 0.25Mpa |
Max. Working temperature | 138℃ |
Time for sterilization | 0~99min |
Time for drying | 0~99min |
Heat average | ≤±2℃ |
Power | 9 KW |
Power voltage | AC 220/380V, three phase |
Product Dimension (mm) | 1400*670*1650 |
Package Dimension (mm) | 1560*820*1930 |
Gross Weight/Net Weight | 378 kg /318 kg |
Automatic sterilization control with digital knob operation, easy to operate, ideal for laboratory, medical, and hospital use.
Built-in drying function, suitable for drying surgical dressings, instruments, and other medical items after sterilization, ensuring complete sterilization and drying in one cycle.
Equipped with over-temperature and over-pressure auto-protection system to ensure safe operation during the entire sterilization cycle.
Automatic power and water cut-off with alarm in case of low water level, providing enhanced safety for continuous use in hospitals, clinics, and laboratories.
Safety interlock mechanism for operator protection:
- The door cannot be opened until the sterilization chamber pressure drops below 0.027 MPa, preventing accidental opening.
- Sterilization process cannot start unless the door is securely closed, ensuring reliable sealing during operation.
Over-pressure protection with safety valve:
- When internal pressure exceeds 0.24 MPa, the safety valve automatically opens to discharge steam into the water tank, maintaining safe internal pressure.
The sterilization chamber is made of SUS304 stainless steel, corrosion-resistant and durable, suitable for long-term operation in medical, dental, and research facilities.
