35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave

Customer Reviews
We deployed over 30 units of Stertek’s vertical autoclaves in public hospitals across Kenya. The products are user-friendly, durable, and perfectly adapted to our local conditions.

—— Health Mission Africa

I'm Online Chat Now

35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave

35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave
35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave 35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave

Large Image :  35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave

Product Details:
Place of Origin: China
Brand Name: Stertek
Certification: CE, ISO13485,ISO9001
Model Number: STV-HC35 to STV-HC100
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 448USD-3000USD
Packaging Details: Standard Export Wooden Case
Delivery Time: 15 working days
Payment Terms: L/C,T/T,Western Union,MoneyGram
Supply Ability: 1000pcs/month
Contact Now Chat Now

35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave

Description
Capacity: 35L, 50L, 75L, 100L Door Structure: Handwheel Door
Number Of Baskets: 2 Pcs Sterilizing Baskets Display: LCD Display
Data Recording: Printer Equiped Exhaust Method: Steam Is Condensed And Then Recycled To Form An Internal Cycle
Drying Function: Optional Drying System Condensate Treatment:: Condenser + Circulation System
Working Temp.: 138℃ Working Press.: 0.25Mpa
Highlight:

100 Liters Vertical Autoclave Machine

,

Fully Automatic Vertical Autoclave Machine

,

Fully Automatic Steam Sterilizer Autoclave

35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave

The Vertical Steam Steriilizer Autoclave 100l are assembled with heating system, micro - computer controlled system, over heat and over pressure protection system, which are reliable for the sterilizing effects, convenient of operation and energy conservation. They are suitable for sterilizing containers, liquids, culture medium, etc. Energy-saving and environmentally friendly, suitable for scientific research or sterilization of liquids and other precise needs that require temperature and humidity control

Vertical Internal Circulation Autoclave Parameter:

Model

STV-HC35

STV-HC50

STV-HC75

STV-HC100

Volume

35 Liters

50 Liters

75 Liters

100 Liters

Sterilizing Chamber Volume

Ø318*450mm

Ø340*550mm

Ø400*600mm

Ø440*650mm

Design Pressure

0.3 Mpa

Max Working Pressure

0.25 Mpa

Design Temperature

150°C

Max. Working Temperature

138°C

Timer

0-99 min or 0-99 hour 59 min

Heat Average

≤± 1°C

Power

2.5 KW

AC220V 50Hz

3 KW

AC220V 50Hz

4.5 KW

AC220V 50Hz

Overall Dimension(mm)

710*490*1150

710*490*1150

750*510*1250

750*510*1250

Transport  Dimension(mm)

740*550*1310

740*550*1310

780*600*1420

780*600*1420

Gross Weight/Net Weight

120kg/95kg

124kg/100kg

137kg/111kg

155kg/129kg

Internal Circulation Sterilizer Details

35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave 0

Laboratory Steam Sterilizer Features:

  1. Full Stainless Steel Construction
    Durable, corrosion-resistant chamber and body ensure long-term use and hygiene compliance.

  2. Quick-Open Door with Hand Wheel Design
    Manual hand wheel structure for fast, safe, and reliable chamber access.

  3. Advanced Door Safety Lock System
    Prevents accidental opening under pressure for maximum operator safety.

  4. Fully Automatic Computer Control
    Intelligent operation covering water filling, heating, sterilization, steam exhaust, and drying—all in one cycle.

  5. Digital Display with Touch Control Panel
    Real-time process visibility and easy operation via modern touch-key interface.

  6. Built-in Over-Temperature and Over-Pressure Protection
    Automatic system safeguards to ensure safe and stable sterilization performance.

  7. Steam-Water Internal Circulation System
    No external steam discharge—keeping the work environment clean, dry, and eco-friendly.

  8. Automatic Water Shortage Protection
    Alerts and halts the process in case of insufficient water level, protecting the equipment and load.

  9. Self-Inflating Silicone Seal
    Ensures airtight sealing during the sterilization cycle without manual adjustment.

  10. Automatic Shut-off with Audible Reminder
    Machine powers off and emits a buzzer sound once sterilization is complete.

  11. Equipped with Two Stainless Steel Sterilization Baskets
    Allows flexible and efficient loading of medical or laboratory instruments.

  12. Integrated Drying Function
    Thorough post-sterilization drying for improved effectiveness and usability.

Application of Vertical  Autoclave:
Laboratory/Scientific Research: glassware, culture medium, surgical instrument kits (must be matched with instrument baskets), biological waste (must be handled in compliance with regulations).
Hospital/Clinic/Medical Health: surgical instrument kits, dressing kits, fabrics.
Pharmaceutical/Bioengineering/Food Industry: production containers, tools, some raw materials/packaging materials (compatibility needs to be confirmed).

Our Factory

35L-100 Inner Circulation Fully Automatic Steam Sterilizer Autoclave 1

Why Choose Us?

  1. Direct Manufacturer Pricing: As the source factory, we eliminate middleman costs, providing global clients cost-effective sterilization solutions directly.

  2. Efficient Direct Support: Our service team ensures rapid and efficient communication and support, handled entirely in-house from production to after-sales.

  3. Flexible Custom Solutions: Leveraging strong technical expertise, we offer both standard models and fully customized equipment tailored to specific structural, functional, or control requirements.

  4. Certified Quality & Safety: Every device undergoes strict quality control and holds international certifications (including CE, ISO 13485, ISO 9001), guaranteeing safety, stability, and long-term reliability.

FAQ

  1. Q: What are your payment terms?
    A: T/T (30% deposit, 70% before shipment); Irrevocable L/C at sight.
  2. Q: What is the delivery time?
    A: About 15 working days for one unit.
  3. Q: What certifications does the sterilizer have?
    A: CE, ISO 13485, ISO 9001.
  4.  Q: What warranty and after-sales support do you offer?
    A: 12-month warranty from installation. We offer:
    ① Remote technical support via phone, email, and video.
    ② Operation & maintenance training (manuals, online/on-site).
    ③ Ample spare parts stock.
    24/7 technical response guaranteed.
  5. Q: How do you ship the Lab Research Autoclave?
    A: Ship by Sea or Air
    ① If you have your forwarder, you can arrange the shipment yourself. We will deliver the goods to the FOB port and cover all local charges before departure.
    ② If you don’t have a forwarder, we can arrange shipping to your designated port under CFR/CIF terms. Freight cost is borne by the customer.
  6. Q: What trade terms do you support?
    A: EXW, FOB, CFR, CIF, and DDP.
  7. Q: Are you a factory or a trading company?
    A: We are a manufacturer with our factory, and we also do trading and sourcing. Most products are made by us, while some are from partners or sister companies to complete equipment sets.
