Quick Open Design Auto Drying 3times Pulse Vacuum Vertical Steam Autoclave

This vertical steam vaccum autoclave are assembled with heating system, micro-computer controlled system, over heat and over pressure protection system, which are reliable for the sterilizing effects, convenient of operation and energy conservation. They are ideal equipments for clinics, scientific research institutes and other organizations to sterilize surgical instruments, fabrics, glasses, culture media etc.

Main Parameter:

Product Details

Product Features:

1. Microcomputer Control with Digital Display
   Intuitive operation via a touch-key panel, with real-time display of temperature, pressure, vacuum level, time, and cycle status.

2. Fully Automatic Sterilization Cycle
   Automated control of all stages—water filling, pulse vacuum, heating, sterilization, draining, steam exhaust, and vacuum drying.

3. Triple Pulse Vacuum Technology
   Achieves a vacuum rate up to -0.081 MPa, ensuring complete air removal from dressings and Class A/B hollow instruments for reliable sterilization.

4. Customizable and Pre-Set Programs
   Includes 4 fixed cycles for instruments, medical dressings, rubber, and liquids. Users can also set custom programs based on specific sterilization needs.

5. PT/TT Test Interface Port
   Built-in testing connectors allow convenient external validation and monitoring of sterilization performance.

6. Multiple Vacuum Drying Cycles
   After sterilization, multiple vacuum drying phases ensure thorough drying and a superior sterilization outcome.

7. 0.22 μm Sterile Bacteria Filter
   Guarantees only sterile air enters the vacuum chamber, effectively preventing secondary contamination during cooling.

8. Quick-Open Hand Wheel Door with Self-Inflating Seal
   Manual wheel design for easy access, combined with an automatic silicone seal for tight, secure chamber closure.

9. Steam-Water Inner Circulation System
   No steam release into the workspace—creating a clean, dry, and user-friendly sterilization environment.

10. Automatic Shut-Off with Audible Reminder
    Sterilizer powers off automatically and alerts the user upon completion of the cycle.

11. Full Stainless Steel Construction
    Made entirely of high-quality stainless steel and equipped with two sterilization baskets for efficient loading.

12. Safety Door Interlock System
    The sterilization cycle cannot start unless the door is sealed; during operation, the door remains securely locked to ensure user safety.

13. Built-In Printer for Real-Time Recording
    Supports live documentation of each sterilization cycle, meeting regulatory and audit requirements.

14. Programmable Start-Time Reservation
    Users can schedule sterilization cycles by setting the date and time (year, month, day, hour, minute) in advance.
